Good Selling Positive PS Offset Printing Paper Plate
Payment Type: | L/C,T/T,D/P |
---|---|
Terms of Trade: | FOB,CFR,CIF,EXW |
Delivery Time: | 30 Days |
Packaging: | Carton wooden |
---|---|
Transportation: | Ocean,Land,Air |
Place of Origin: | China |
Supply Ability: | Strong |
Port: | ShangHai Port,Ningbo Port |
Product Description
China good selling wholesale positive ps Offset Printing Paper plate
Shelf life :
18 months when stored in a light-free area away from excessive cold, heat and high humidity
Transport and storage:
Store plates at in their packaging, away from excessive cold, heat or high humidity. Recommended condition is: temperature 10-26°C & RH between 40 - 70%.
YP-II POSITIVE PS PLATE | |
Plate type | Positive |
Application | Commercial sheetfed and rotary press printing |
Substrate | Electro-chemically grained and anodized lithographic aluminum. |
Gauge | 0.15/0.25/0.30/0.40mm |
Maximum width | 1320mm |
Spectrum scope | 350-420nm |
Sensitivity | 130-150mj/cm2 |
Safe light | UV filtered or Yellow light |
Coating color | Green |
Dot reproduction | 2%-98%@ 200lpi Depend upon capability of imaging device |
Run length | Above 100,000 |
Developer | Huaguang PD developer (concentrated solution), |
Development | 1 liter can process 15 sqm Developer dilute ratio: 1:4(machine)-1:6(hand) Developing Temperature: 24-26℃ Developing Time: 20-30secs |
Packaging | 0.15mm 100 pieces/box 0.25/0.30mm 50 pieces/box if length <1030mm; 30 pieces/box if length ≥1030mm; 25 pieces/box if the area > 1m2 |






SUZHOU HUAGUANGBAOLI PRINTING PLATE CO.,LTD
Professional Manufacturer For Printing Plates--Ctp Plate, Ctcp Plate, Ps Plate, Graphic Film,Violet Ctp Plate, Mother Company Is Huaguang Group In China.
Huaguang HSV violet CTP plate allows for consistent printing performance with high-quality results for sheet-fed and web printing. The plates and chemicals are compatible with a variety of CTP plate processing systems, configured for either automated or operator- assisted production environments.
Huaguang HSV violet CTP plate combines wide exposure latitude with consistent, durable printing that can yield 250,000 impressions (1,000,000 impressions with post baking). In addition, excellent water/ink balance ensures less waste and greater value in the make-ready stage of printing. The scratch-resistant photosensitive coating and excellent printing performance can protect the plate, allowing faster roll-up and less paper waste.
Company Info
- Company Name: SUZHOU HUAGUANGBAOLI PRINTING PLATE CO.,LTD
- Representative: Xikun Du
- Product/Service: CTP PLATE , CTCP PLATE , PS PLATE , GRAPHIC FILM , VIOLET CTP PLATE , FLEXO PLATE
- Capital (Million US $): 37 million
- Year Established: 2004
- Total Annual Sales Volume (Million US $): US$10 Million - US$50 Million
- Export Percentage: 51% - 60%
- Total Annual Purchase Volume (Million US $): US$2.5 Million - US$5 Million
- No. of Production Lines: 2
- No. of R&D Staff: 5 -10 People
- No. of QC Staff: 5 -10 People
- OEM Services Provided: yes
- Factory Size (Sq.meters): 10,000-30,000 square meters
- Factory Location: DAHE INDUSTRIAL ZONE,SHANGHU TOWN,CHANGSHU,SUZHOU ,JIANGSHU PROVINCE,PRC.
- Contact Person: Mr. Zhubingde
- Tel: 86-512-52409961
